FLGS-SRIBB Series
High voltage photoelectric storage diesel hybrid system
Category: Commercial and industrial energy storage
Product description
Product Features
Posture monitoring system with built-in mobile app for remote detection;
Built-in 51.2V lithium battery, 4-15 battery modules, 30-200kW hybrid inverter, solar/AC charger; · Modular and stackable design for easy installation and expansion;
Built-in intelligent BMS with communication protocols.
LiFePO4 battery has high cycle time, more than 8000 charge-discharge cycles. It has MPPT solar charging and AC charging functions.
Technical parameter
| Product model | SRIBB-30K | SRIBB-50K | SRIBB-100K | SRIBB-150K | SRIBB-200K |
| Inverter/charger | Hybrid inverter | ||||
| Inverter type | 30kw | 50kw | 100kw | 150kw | 200kw |
| Output rating | 30kw | 50kw | 100kw | 150kw | 200kw |
| Output voltage waveform | Pure sine wave | ||||
| Output voltage | 380Vac50Hz | ||||
| Low dc warning voltage | Each battery pack 44.8Vdc. | ||||
| Low dc cut-off voltage | Each battery pack 43.2Vdc. | ||||
| Low dc warning return voltage | Each battery pack 44.8Vdc. | ||||
| Total charging current(grid + solar) | Maximum 200A | ||||
| High charging voltage | Each battery pack 58.6Vdc. | ||||
| Floating charge voltage | Each battery pack 57.6Vdc. | ||||
| Lithium cell | 4 to 15 battery series | ||||
| Standard battery module | 51.2v280Ah*5 | ||||
| Normal capacity (25℃, 0.2C) | 14336Wh | ||||
| Rated battery voltage | 200-1000V | ||||
| Maximum charging current | 200A | ||||
| Maximum discharge current | 200A | ||||
| Operating voltage range | 44.8Vdc to 58.4Vdc per battery pack | ||||
| Cycle life | > 8000 times 80% DOD at 25°c | ||||
| Working temperature | -23℃-+65℃ | ||||
| Ac Input | |||||
| Rated input voltage | 220/380V, 230/400V0.85Un-1.1Un | ||||
| Input voltage range | 220/380v, 230/400V0.85Un-1.1Un | ||||
| Frequency range | 40~70hz, default | ||||
| Primary topology | L+N+PE | ||||
| Minimum input voltage | 210Vac | ||||
| Maximum ac input voltage | 420Vac | ||||
| Rated current (effective value) | 36+36+36+36A | ||||
| Maximum current (rms) | Maximum 144A | ||||
| Solar Input | |||||
| Rated photovoltaic voltage | 1000Vdc | ||||
| Mppt voltage range of photovoltaic array | 150vdc~850Vdc | ||||
| Maximum open circuit voltage | 1000Vdc | ||||
| Solar charging current | Maximum 200A | ||||
| Protection | |||||
| Protection | Overcharge protection, overdischarge protection, overcurrent protection, short circuit protection, overheat protection | ||||
| Ambient temperature | |||||
| Noise (db) | <30℃<40dB (1 meter) | ||||
| Working temperature | -23℃~+65℃ | ||||
| Humidity | 0~95% (no condensation) | ||||
| Sea level (m) | <6000 | ||||
| Other | |||||
| Productiveness | 92.0% | ||||
| Guarantee | 3 years | ||||
